Description
This is a BRAND NEW GE Genteq Carrier/Bryant/Payne/ICP/Heil/Tempstar Furnace ECM BLOWER MOTOR. The GE Genteq Part # is 5SME39NXL354. The ICP/Heil/Tempstar # is 1177601. It's 3/4 HP 208-230 volt and 1050 RPM. The motor is 5 5/8" in diameter (Frame 48Y). The shaft extends 4" out of the motor and is 1/2" in diameter. If the shaft is facing up (as seen in the picture) the rotation is clockwise. Thanks for looking and good luck!
Function:
An electric motor converts electrical energy into mechanical energy. In an HVAC system, motors typically turn the air conditioning fan blade and the furnace blower motor. Newer high efficient motors, such as X13 and ECM motors, have "end caps" that control the motor speeds. These can be removed and replaced separately.
Replaces Old Part #s:
1176460
Repair Difficulty Level:
Partial List of Units that Use This Item:
Hit Ctrl+F and enter your model number for a quick search!
