Description
This is a new Furnace Blower Motor. It is designed to replace the now obsolete part #s listed below. It is a 1/4 HP 230v 1050 RPM 3-speed blower motor with reversible rotation. The old black motor is shown in the second picture.
This new motor requires a 7.5 MFD capacitor (Buy one Here)
| Old Motor | New Motor |
| Black | Black |
| Red | Red |
| Orange | White |
| Brown (x2) to the required capacitor | |
| Flip orange/yellow wires to reverse rotation |
Function:
An electric motor converts electrical energy into mechanical energy. In an HVAC system, motors typically turn the air conditioning fan blade and the furnace blower motor. Newer high efficient motors, such as X13 and ECM motors, have "end caps" that control the motor speeds. These can be removed and replaced separately.
Replaces Old Part #s:
1468-120 S1-1468-120 1468120
Repair Difficulty Level:
Partial List of Units that Use This Item:
Hit Ctrl+F and enter your model number for a quick search!
